Bendix ACom® PRO Diagnostics – Professional Brake & Safety System Diagnostic Software

Bendix ACom® PRO Diagnostics is a professional Windows-based diagnostic software designed for servicing, troubleshooting, calibrating, and repairing Bendix electronic braking, stability, collision mitigation, and driver assistance systems used in commercial trucks, buses, and trailers.

Developed for heavy-duty diesel technicians, fleet maintenance providers, and commercial vehicle workshops, the software provides complete access to Bendix electronic control units (ECUs), allowing users to diagnose faults, perform system calibrations, configure components, and maintain advanced vehicle safety systems.

Supported Systems

Supports diagnostics and service for:

✔ Anti-lock Braking Systems (ABS)
✔ Automatic Traction Control (ATC)
✔ Electronic Stability Control (ESC)
✔ Bendix EC-60 & EC-80 Electronic Controllers
✔ Collision Mitigation Systems (FLC-20, FLR-20, FLR-21 and more)
✔ Bendix Wingman® Driver Assistance Systems (Wingman ACB, Wingman Advanced & Wingman Fusion)

Key Features

✅ Complete diagnostics for Bendix electronic safety systems
✅ Read and clear Diagnostic Trouble Codes (DTCs)
✅ System calibration and configuration support
✅ ECU communication and advanced troubleshooting
✅ Supports VORAD VS400 and VS500 radar systems
✅ Bendix Driver Interface Unit (DIU) diagnostics
✅ SafetyDirect Processor (SDP) support
✅ AutoVue 3G & 4G Lane Departure Warning Systems
✅ BlindSpotter object detection diagnostics
✅ SmartTire® Tire Pressure Monitoring System (TPMS) support
✅ Pneumatic Disc Brake (ADB2ZX) pad wear sensor diagnostics
✅ TrailerLink® TPMS support for trailers

Trailer System Coverage

Supports diagnostics and configuration for:

✔ Bendix TABS6 Standard
✔ Bendix TABS6 Premium
✔ Bendix TABS6 Advanced
✔ EC-17 Electronic Controller
✔ EC-30 & EC-30T Controllers
✔ MC-30 ABS Module
✔ A18 Trailer ABS System
✔ ABS U1x (Generation 4)
✔ ABS2x (Generation 5)

Supported Diagnostic Interfaces

• Dearborn DPA5
• NEXIQ USB-Link 1
• NEXIQ USB-Link 2
• Noregon DLA 2.0
• Noregon DLA+ 3.0

System Requirements

• Windows 10 or Windows 11
• Minimum 8 GB RAM
• 2.5 GHz or faster processor
• 5 GB free disk space

Recommended Setup

For the best performance and maximum reliability, it is recommended to install Bendix ACom PRO on a dedicated Windows PC used exclusively for heavy-duty diesel diagnostics. This helps prevent software conflicts, improves system stability, enhances security, and ensures consistent diagnostic performance.

Important Information

• License: Activation for 1 PC
• After purchase, our technical support team will provide remote installation, activation, and configuration assistance to ensure the software is fully operational.

Bendix ACom® PRO Diagnostics is an essential diagnostic solution for commercial vehicle repair shops, fleet maintenance facilities, diesel technicians, and trailer service professionals requiring advanced diagnostics, calibration, troubleshooting, and maintenance of Bendix braking, stability control, collision mitigation, and driver assistance systems.
